Item: DPS5





Vendor Note:

Ground Orders Ship In 3-5 Business Days\n
Lifetime Warranty on All Products

DPS5

Vendor: Altronix Corporation

Altronix DPS5 power supply/charger converts a low voltage AC input into a 6VDC, 12VDC or 24VDC output. This unit has a wide range of applications for access control, security and CCTV system accessories that require additional power.

Notes: n/a

List: $89.71

Dealer: $N/A

Features
  • 6VDC applications use TP1640.
  • 12VDC applications use T2428100.
  • 24VDC applications use T2428175.
  • 6VDC, 12VDC or 24VDC selectable output.
  • 4.0A continuous supply current.
  • Filtered and electronically regulated output.
  • Short circuit and thermal overload protection.
  • Built-in charger for sealed lead acid or gel type batteries.
  • Automatic switch over to stand-by battery when AC fails.
  • Battery short circuit protection (circuit breaker).
  • AC input and DC output LED indicators.
  • Extremely compact design.
  • Includes battery leads.
  • Snap Track compatible (order Altronix model number ST3).
  • Relative Humidity 85% +/- 5%.
  • BTU/Hr. (approx.):
  • 6VDC: 12 BTU/Hr.
  • 12VDC: 25 BTU/Hr.
  • 24VDC: 49 BTU/Hr.
  • System AC input VA requirement:
  • 6VDC: 55.2VA.
  • 12VDC/24VDC: 115VA
Other Information
Install Hours: 1 *
Phase: Finish
Industry: n/a
Voltage: n/a
Rack Mount: No
Rack Units: 0
Bulk Wire: No
Diameter: 0
* Product install times are provided for reference purposes only. Actual install time may vary. Product install times indicate estimated time to install the product under normal conditions based on industry research and does not take into account other considerations such as travel, un-boxing, programming, commissioning, or other factors.
